Jeep Flat Front Fender Flares w/ LED Lights ( 18-25 Jeep Wrangler JL & 20-25 Gladiator JT) - Hooke Road

PRODUCT SPECIFICATIONS

HIGHLIGHS

• Product weight: about 119 lbs
• Package includes: Bed rack assembly, mounting hardware, Installation info
• Fully bolt-on installation, shipped disassembled, easy to put together

• Textured black powder coat finish & Premium E-coating process inside
• Extra protection from road and trail debris. Features a width of 5.7-inch on the top of the fender flares
• Equipped with LED lights that work as turn signal lights and daytime running lights (DRL)
• Heavy-duty 16-gauge(1/16 inch) steel plate for the fender, and 11-gauge(1/8 inch) steel for the mounting brackets
• Aggressive angular flat fender flares that make your vehicle out of the crowd.
  Provides additional tire coverage

DIMENSION

Bolt-on Installation Guide and Wiring Operation.

 1.  Remove factory front fender flares and inner fender liners. Clean the area.
 2.  Align the new fender flares with the mounting holes on the vehicle body. Secure them using M820 button head socket cap bolts, M820*1.5 flat washers, and M8 flange hex lock nuts. Tighten securely, but avoid overtightening.
 3.  Connect the wiring harness:
        Negative (black) to factory black wire
        DRL (red) to factory white/green wire
        Turn signal (yellow) to factory white/yellow wire. Install a load resistor if needed to prevent hyper flashing.
 4.  Secure the wiring neatly with clips, tape, and zip ties.
 5.  Reinstall the inner fender liners, ensuring they don't interfere with the new fender flares.
